ORECA FLM-09

A true formula for access to endurance, the FLM09 has initiated many vocations for this sport for at lot of teams around the world.

Back to All Oreca LMP Cars

TECHNICAL SHEET

Chassis
- Carbon fibre monocoque & Honeycomb
- Length: 4600 mm
- Width: 1990 mm
- Height: 1025 mm
- Front track: 1647 mm
- Rear track: 1609 mm
- Wheelbase: 2870 mm
- Weight: around 900 kg
En savoir plus
Engine
- V8 GM based
- Power: around 430 bhp
- Torque: around 630 Nm
- Max. revs: around 6000 rpm
- Lubrification : dry sump
- Electronic management system: Magneti Marelli
En savoir plus
Suspensions & Tires

Double steel wisbones with pushrod

Front tyres : 12,5″x18″

Rear tyres : 13″x18″

En savoir plus

Gearbox
- Make : Xtrac
- Type : Sequential
- Gear change : Steering wheel-mounted paddles
- Ratios : 6 + reverse
En savoir plus
Brakes
- Ventilated carbon discs
- Make : Brembo
- Front discs : Brembo 380 mm x 37
- Rear discs : Brembo 355 mm x 37 mm
- Calipers : Brembo monobloc 6 pistons
- Pads : Brembo
En savoir plus
Safety Equipment
- 6-point harness adapted to the HANS system
- Flexible fuel tank (75L)
En savoir plus
Bodywork
- Carbon/kevlar
- Race in : European Le Mans Series, ALMS, Asian Le Mans Series
En savoir plus

PALMARES

2016
PROTOTYPE CHALLENGE – USA
- Drivers : Alex Popow (VEN) & Renger Van der Zande (NED)
- Teams : Starworks Motorsport
En savoir plus
2015
PROTOTYPE CHALLENGE – USA
- Drivers : Jon Bennett (USA) & Colin Braun (USA)
- Teams : CORE Autosport
En savoir plus
2014
PROTOTYPE CHALLENGE – USA
- Drivers : Jon Bennett (USA) & Colin Braun (USA)
- Teams : CORE Autosport
En savoir plus
2013
LMPC EUROPE
- Drivers : Gary Hirsch (SUI) & Paul Loup Chatin (FRA)
- Teams : Team Endurance Challenge
LMPC – USA
- Drivers : Mike Guasch (USA)
- Teams : CORE Autosport
En savoir plus
2012
LMPC EUROPE
- Pilotes : John Hartshorne (GBR)
- Teams : Boutsen Ginion Racing
LMPC – USA
- Drivers : Alex Popow (VEN)
- Teams : CORE Autosport
En savoir plus

2011
FORMULA LE MANS – EUROPE
- Drivers : Julien Schell (FRA), Mirco Schultis (GER) et Patrick Simon (GER)
- Teams : Pegasus Racing
LMPC – USA
- Drivers : Eric Lux (USA), Gunnar Jeannette (USA) et Ricardo Gonzalez (MEX)
- Teams : CORE Autosport
En savoir plus
2010
FORMULA LE MANS – EUROPE
- Drivers : Andrea Barlesi (BEL) & Gary Chalandon (FRA)
- Teams : DAMS
LMPC – USA
- Drivers : Scott Tucker (USA)
- Teams : Level 5 Motorsports
En savoir plus
2009
FORMULA LE MANS CUP
- Drivers : Nico Verdonck (BEL) & Gavin Cronje (RSA)
- Teams : DAMS
En savoir plus
